Capacity:
0.5-16t/h
Customization:
Suitable for more than 200 kinds of materials in the industries of minerals, chemicals, building materials, etc., which are not flammable and explosive and have a Mohs hardness of no more than 9 and a humidity of less than 6%. The particle size of the finished powder can be adjusted arbitrarily within the range of 30-500 mesh.
The grinding roller rolls on the grinding ring and grinds it, and the fan blows the ground fine powder to the classifier for sorting.
Compact structure, small footprint, easy operation and maintenance, can separate coarse powder and fine powder, and produce uniform powder size.
Widely used in the grinding of non-metallic minerals, such as calcite, limestone, kaolin, bentonite, talc, barite, gypsum, etc., and is often used to prepare fine powders.
| Model | Number of grinding rollers (pieces) | Grinding ring | Maximum feed size (mm) | Discharge size (mm) | Power of main machine (kw) | Processing capacity (t/h) | |||
| Pieces | Diameter (mm) | Height (mm) | Inner diameter (mm) | Height (mm) | |||||
| MR-2615 | 3 | 260 | 150 | 780 | 150 | <15 | 0.004-0.156 | 18.5 | 0.5-2 |
| MR-2715 | 3 | 270 | 150 | 830 | 150 | <15 | 0.004-0.156 | 22 | 0.8-3.5 |
| MR-3016 | 3 | 300 | 160 | 880 | 160 | <20 | 0.004-0.156 | 30 | 1-4 |
| MR-3216 | 4 | 320 | 160 | 970 | 160 | <25 | 0.004-0.156 | 37 | 1.6-5.2 |
| MR-4121 | 5 | 410 | 210 | 1280 | 210 | <30 | 0.033-0.95 | 75 | 3-9 |
| MR-4427 | 6 | 440 | 270 | 1600 | 270 | <35 | 0.045-1.9 | 132 | 8-16 |
